Revolve Valves

Motorizgd Actuator Single Phase Quarter Turn

KEY FEATURES

SUPPLY VOLTAGE

230 V AC (± 10%), 50/60 Hz
110 V AC, 24V DC, 12V DC (Available on request)

ENCLOSURE - IP 67/68

Weatherproof -
Flameproof or Ex-Proof -

TORQUE RANGE

15 Nm to 5000 Nm

INTEGRAL STARTER UNIT

Selector Switches	Open / Stop / Close Auto / Manual or Remote / Local
Indicator Lamps	Open / Stop / Error

VARIOUS OPTIONS

ON / OFF Type.
Modulating Control (Signal Input - 4 ∼ 20mA/1 ∼ 5V DC / 2 ∼ 10V DC).
Potentiometer Feedback (4 ∼ 20mA).
Auxiliary Limit Switches (2 Units).
2 Wire for ON/OFF Operation.

MOTORIZED VALVES

∼ Ball Valves
∼ Butterfly Valves / Damper Valves
∼ Fire Safe Ball Valves
∼ Jacketed Ball Valves
∼ Wafer Ball Valves
∼ UPVC / PP Ball Valves

SINGLE PHASE MOTORIZED BALL VALVES

2 Way Ball Valve
Electrical Actuator Operated

SIZE :
1/2" TO 4" Screwed to BSP/ NPT
MOC:
WCB/ SS 304/ SS 316/ SS 316L
REPLACEABLE SEAT :
PTEE/ Glass Filled PTFE/ CFT
TEMP. :
220° C / 400° C (On Request)
DESIGN & MANUFACTURING STD. :
BS 5351 / BS 6755

2 Way Ball Valve
Electrical Actuator Operated

SIZE :
1/2" TO 8" Flanged End 150# / 300# / 600# / 900# / 1500#
MOC:
WCB/ SS 304/ SS 316/ SS 316L/ Alloy Steel / Duplex
REPLACEABLE SEAT :
PTEE/ Glass Filled PTFE/ CFT
TEMP. :
220° C / 400° C (On Request)
DESIGN & MANUFACTURING STD. :
BS 5351 / BS 6755

3 Way/ 4 Way/ Ball
Valve Electrical Actuator Operated

SIZE :
1/2" TO 4" Screwed to BSP/ NPT
1/2" TO 8" Flanged End 150# / 300#
MOC:
WCB/ SS 304/ SS 316/ SS 316L
REPLACEABLE SEAT :
PTEE/ Glass Filled PTFE
TEMP. :
220° C
PORT :
'L' Port / 'T' / 'X' Port
DESIGN & MANUFACTURING STD. :
BS 5351 / BS 6755

PP / UPVC Ball Valve
Electrical Actuator Operated

SIZE :
1/2" TO 4" Screwed to BSP/ NPT
1/2" TO 4" Flanged
MOC:
PP / UPVC / CPVC / PVDF LINED
REPLACEABLE SEAT :
PTEE/ Glass Filled PTFE/ CFT
TEMP. :
180° C
DESIGN & MANUFACTURING STD. :
BS 5351 / BS 6755

SINGLE PHASE MOTORIZED BUTTERFLY VALVES

Wafer Type Butterfly Valve
Electrical Actuator Operated

SIZE :
1.1/2" TO 40"
MOC:
CI / DI / WCB / SS 304 / SS 316 /
Alloy Steel / Duplex
MOULDED / REPLACEABLE SEAT :
Nitrile (NBR) EPDM / VITON /
Teflon Muffler
ENDS :
Wafer
RATING :
PN 6/ PN 10/ PN 16/ PN 20/ PN 25
DESIGN & MANUFACTURING STD. :
API 609 Category A / BS 5155/
MSS SP-67 / AWWA C-504

Double Flanged Butterfly Valve
Electrical Actuator Operated

SIZE :
1.1/2" TO 40"
MOC:
CI / DI / WCB / SS 304 / SS 316 /
SS 316 L /Alloy Steel / Duplex
SEAT :
Nitrile (NBR) EPDM / VITON
ENDS :
Double Flanged
RATING :
PN 6/ PN 10/ PN 16/ PN 20/ PN 25
DESIGN & MANUFACTURING STD. :
API 609 Category A / BS 5155/
MSS SP-67 / AWWA C-504

High Performance Butterfly Valve Electrical Actuator Operated

SIZE :
1.1/2" TO 24"
MOC:
CI / WCB / SS 304 / SS 316 / SS 316L Alloy Steel / Duplex
REPLACEABLE SEAT :
PTEE/ Glass Filled Teflon / VITON/ Metal To Metal
ENDS :
Wafer & Double Flanged
RATING :
150# / 300#
DESIGN & MANUFACTURING STD. :
API 609 Category B / MSS SP -68 / AWWA C-504

PP / UPVC Butterfly Valve
Electrical Actuator Operated

SIZE :
1.1/2" TO 24"
MOC:
PP / UPVC / CPVC / PVDF LINED
REPLACEABLE SEAT :
Nitrile (NBR) / EPDM / VITON
ENDS :
Wafer
DESIGN & MANUFACTURING STD. :
ANSI / DIN
